Genie CCTV GC3JB Colour Junction Box And Thermostat Camera
Product Overview
Genie CCTV GC3JB Standard Resolution Colour Camera in a Wall Mount Junction Box, 380TVL, 1/3" Sony CCD, 0.5 Lux, 12V DC 100mA, Con. Pinhole 3.6mm Lens.
Key Features
- Sony 1/3” High Resolution Colour Super HAD CCD
- Digital Noise Reduction (DNR)
- Up to 70% Disk Saving with DNR Technology
- Automatic Gain Control Built-In
- Automatic White Balance
- Genuine ABS Junction Box, Grey in Colour
Technical Specification Genie CCTV GC3JB
Model Number
| Genie CCTV GC3JB |
| Image Sensor | Sony 1/3-inch Interline Colour CCD |
| Horizontal Resolution | 380TVL Colour – 512 x 582 Pixels |
| Electronic Shutter | 1/50 – 1/100,000 Seconds |
| Sensitivity | 0.5 Lux @ F1.2 |
| Signal To Noise Ratio | Greater Than 45dB (AGC Off) |
| White Balance | Automatic |
| Lens | 3.6mm Conical Pinhole |
| Power Consumption | 100mA |
| Video Output | 1V p-p ~ 75 Ohm |
| Dimensions (W x H x D) | 80 x 80 x 50 mm |
| Power Supply | 12V ± 10% |
| Operating Conditions | Temperature: -10°C ~ +50°C, Humidity: 10% ~ 90% RH |
