Fermax 2405 Access MDS Digital Central unit

Fermax 2405 Access MDS Digital Central unit
  Zoom
Our Price:  £184.96
List Price:  £272.00
Saving Of:  £87.04 (32%)
(Exc. 20% VAT)(£221.95 Inc. VAT)
+

Catalogue No:  2405
Brand:  Fermax

Current Item:



Click for delivery info

Fermax


Special Offer:  Free delivery is available when you order £250.00 or more of selected products.

Fermax 2405 Access MDS Digital Central unit

The MDS central unit is the controller for MDS Digital audio/video door entry and access control systems. Lets you integrate the following functions:

  • Video door entry system with electronic directory and multiple guard units.
  • Access control for residents.
  • Lift control for residents and visitors.
  • Automated services: switching on/off lighting, irrigation, purification, etc.
  • Technical alarms in the community and home.
  • Intercommunication between guard units and elevators, garages, stair landings.

Being able to integrate all these functions in the same equipment mean a great saving by sharing resources and infrastructures (wiring, controllers) and simplicity of management: one-person maintenance and management.

Communication with all devices is by means of communication buses that enormously facilitate installation of the product.

Each central unit comes provided with a PC configuration and administration software (Wincom+) with the following functions:

  • User authorizations and cancellations: electronic directory, access control.
  • Access restrictions configuration.
  • Incidents record.
  • Installation test.
Power supply: 12 Vdc
Consumption: 150 mA
Operating temperature: 10 to 60 ºC
Programming software: Wincomplus (Cd included with central unit)

  • Audio and Video Door Entry System (MDS Digital)
  • Capacity for up to 32 accesses, between audio and/or video panels and guard units, (using switcher modules Ref. 2379) per central unit.

If there are several central units (more than one) interconnected via FXL network, the capacity per central unit is 31 accesses.

  • Capacity for up to 10 Central Guard Units per central unit (each Central Guard Unit is equivalent to one access).
  • Handles up to 9.999 homes.
  • Residents electronic directory: name, flat, door, etc. … with capacity for up to 1022 users.
  • User personal codes.
  • Up to 999 audio panels for intercommunication of 1 or 2 pushbuttons by means of panel decoders.
  • Possibility of connection between central units (up to a total of 63) via FXL Network.
  • Incidents record. Records are stored in the central guard unit’s internal memory (Off-line mode) and in the PC (On-line mode).
  • Possibility of management by PC and remote management by IP or modem (by means of additional modules).


* Access Control System (Digital MDS Controller)
It has all the features of the MDS DIGITAL AUDIO and VIDEO DOOR ENTRY system and specific access control functions:
- 32 accesses per Central Unit: keypad accesses, proximity card, RF, etc. If audio accesses are not used, the switcher modules are not necessary.
If there are several central units (more than one) interconnected via FXL network, the capacity per central unit is 31 accesses.

  • Up to 63 Central Units connected to each other.
  • Up to 1022 users.
  • Up to 999 sensors (by means of sensor decoders) per central unit.
  • Up to 999 relays (by means of relay decoders) per central unit.
  • PC software for programming and management of the installation (local and remote).
  • Technical alarms and automation (by means of sensor decoders and relays).
  • Intercommunication: Up to 999 audio panels for intercommunication of 1 or 2 pushbuttons by means of panel decoders and Central Guard Unit.
DIN 10 dimensions: 175x 90 mm x60 mm

Power supply:
  • Audio: 12 Vdc
  • Video: 18 Vdc
Power supply: 12 Vdc
