Genie CCTV GMC3CHIR D/N Micro-Cannon IR Vandal Camera With 3mm Fixed Lens, White
Product Overview
Genie CCTV GMC3CHIR Micro-Cannon Vandal Resistant IR Camera, 1/3" Sony Super HAD CCD, 540 TVL, Compact (Only 48mm Diameter), Vandal Resistant Housing, Cast Aluminium Construction, 3.0mm Fixed Lens, 10 pc IR LEDs, 0 Lux, IP66, DC 12v, Available in Colours; Black.
Key Features
- 1/3” Sony Super HAD CCD
- Super High Resolution, 540 TVL
- Compact Size (Only 48mm Diameter!)
- Vandal Resistant Housing
- Cast Aluminium Construction
- Integrated Fixed Lens
- Digital Day / Night
- 10 Pc IR LEDs (3m Range)*
- Weatherproof (IP66 Rated)
- DC 12V
- Illumination distance quoted above is based on optimal conditions
Technical Specification Genie CCTV GMC3CHIR
Model Number
| Genie CCTV GMC3CHIR |
| Image Sensor | 1/3” Sony Super HAD CCD |
| Horizontal Resolution | 540 TVL |
| Sensitivity | 0.1 Lux (Col), 0 Lux with IR O |
| Lens | 3.0mm Fixed Lens |
| Effective Pixels (H x V) | 752 x 582 |
| Electronic Shutter Speed | Auto/Manual 1/50 ~ 1/100,000 Seconds |
| Scanning System | 2:1 Interlace |
| Synchronisation | Internal |
| Frequency | Horizontal: 15.625KHz Vertical: 50Hz |
| Video Output | 1.0Vp-p~75 Ohm |
| Day/Night | Auto |
| S/N Ratio | >48dB (AGC Off) |
| Gain Control | Auto |
| White Balance | Auto |
| IR LEDs & Illumination Distance | 10 Pcs (3 Metres Range*) |
| IP Rating | IP66 |
| Operating Conditions | Temperature: -10°C ~ +50°C, Humidity: 30 ~ 90% RH |
| Power Supply | DC 12V |
| Power Consumption | 120mA (With IR Off), 200mA (With IR On) |
| Dimensions (W x H x D) | 48 x 37 x 48 mm |
| Weight | 90g |
| *Illumination distance quoted above is based on optimal conditions. | |
