CDVI 2Easy 2 wire CDV97-ID 1 button Door station with Prox
NB: The CDV97-ID ships as one unit CDV97-4ID 4 button call point with a cover plate which when installed hides 3 buttons, converting the unit to a 1 button call point
1-button master door station Up to 32-way (with extensions) Integral prox reader Backlit nameplates 2-wire non polarised Up to 4 entrances Rated IP64
Single call button, system design tips:
Use this video door entry call point with CDVI 2Easy range of products, minimum requirement is - 1 call point, 1 monitor, 1 power supply part No. CDV-PC6
NB: Single button video systems can be ordered as complete kits
Single call button systems only support 1 X CDV47DX wi-fi monitor - for additional monitors please select from list of compatible part numbers below
- CDV-47-B (matching 7" touchscreen hands free monitor non wi-fi curretly only available in black)
- CDV-43 (4.3" hands free monitor, neat design with touch buttons built in only available in white)
- CDV-24 (4" wall mounted monitor with handset on coiled wire ideal for noisy environments only available in white)
- CDV-17HFA (Audio only hands free unit ideal for lesser used areas i.e. attic landing, garden shed etc.
Don't forget, if you order additional monitors you should order a 4 way distributor for systems up to 4 monitors in total - part No. CDV-DBC4A
For wiring diagrams, see below
For larger systems with multiple call buttons, please call us for design support
Wiring is simple
Wiring example
2 Doors to 4 monitors using 2 core cables
Diagram shows 2 X CDV91-SF connected to CDV-DBC4A connected to CDV-PC6 output to CDV-DBC4A with 4 X CDV47 monitors
Other combinations can be used to achieve any configuration required up to 4 entrances maximum, you can combine different monitors and even use audio only for lesser used locations, i.e. in the cellar.
