Samsung techwin HCP-6230H 2MP PTZ Coax Camera 23x zoom

Catalogue No: HCP-6230H

£975.94

(Exc. 20% VAT)

(£1,171.13 Inc. VAT)

Delivery info

–

Information

Samsung techwin HCP-6230H 2MP PTZ Coax Camera 23x zoom

Full HD (1920 x 1080, 30fps) Resolution. 0.2Lux@F1.6 (Color), 0.01Lux@F1.6 (B/W). Powerful 23x Zoom (4.44 ~ 101.2mm), Digitial 16x. Day & Night (ICR), Defog, WDR (120dB), SSNRIII. IP66 / IK10. Preset : 700˚/sec, Azimuth. RS-485, Coax Control.

Key Features

Full HD (1920 x 1080, 30fps) Resolution
0.2Lux@F1.6 (Color), 0.01Lux@F1.6 (B/W)
Powerful 23x Zoom (4.44 ~ 101.2mm), Digitial 16x
Day & Night (ICR), Defog, WDR (120dB), SSNRIII
IP66 / IK10
Preset : 700˚/sec, Azimuth
RS-485, Coax Control

Specifications

VIDEO
Imaging Device	1/2.8" 2.38M CMOS
Total Pixels	1,952(H) x 1,116(V), 2.18M pixels
Effective Pixels	1,944(H) x 1,104(V), 2.14M pixels
Scanning System	Progressive
Min. Illumination	Color : 0.2Lux (1/30sec, F1.6) B/W : 0.01Lux (1/30sec, F1.6)
S / N Ratio	50dB
Video Output	BNC (CVBS / AHD)
LENS
Focal Length (Zoom Ratio)	4.44 ~ 101.2mm (Optical 23X)
Max. Aperture Ratio	F1.6 (Wide) / F3.63 (Tele)
Angular Field of View	Wide : 1.4m (4.59ft), Tele : 1.9m (6.23ft)
Min. Object Distance	Wide : 1.5m (4.92ft), Tele : 2m (6.56ft)
Focus Control	Auto / Manual / One Push
Lens Type	DC Auto Iris
Mount Type	Board-in Type
PAN / TILT
Pan Range	360° Endless
Pan Speed	Preset : 700°/sec, Manual : 0.024°/sec ~ 200°/sec
Tilt Range	210° (-15° ~ 195°)
Tilt Speed	Preset : 700°/sec, Manual : 0.024°/sec ~ 200°/sec
Preset	255ea
Preset Accuracy	±0.2°
Azimuth	Yes (E / W / S / N / NE / SE / NW / SW OSD)
OPERATIONAL
Camera Title	Off / On (Displayed up to 15 Characters)
Day & Night	Auto (ICR) / Color / B/W
Backlight Compensation	Off / BLC / HLC
Wide Dynamic Range	120dB
Contrast Enhancement	SSDR (Off / On)
Digital Noise Reduction	SSNRIII (2D + 3D Noise Filter) (Off / On)
Digital Image Stabilization	Off / On
Defog	Off / Auto / Manual
Motion Detection	Off / On (4ea Rectangle Zone)
Privacy Masking	Off / On ( 32 Zones of Rectangle Zone)
Gain Control	Off / Low / Middle / High
White Balance	ATW / AWC / Manual / Indoor / Outdoor / Mercury / Sodium
Electronic Shutter Speed	Minimum / Maximum / Anti Flicker (2 ~ 1/12,000sec)
Digital Zoom	16x
Flip / Mirror	Off / On
Intelligent Video Analytics	Tampering, Virtual Line, Enter / Exit, Appear / Disappear
Alarm I/O	Input 4ea / Output 2ea (Relay)
Remote Control Interface	RS-485, Coaxial
Protocol	RS-485: Samsung-T/E, Pelco-D/P, Sungjin, Panasonic, Bosch, AD, GE, Vicon, Honeywell Coaxial : ACP (AHD Coax Protocol)
ENVIRONMENTAL
Operating Temperature / Humidity	-50°C ~ +55°C (-58°F ~ +131°F) / Less than 90% RH
Storage Temperature / Humidity	-50°C ~ +60°C (-58°F ~ +140°F) / Less than 90% RH
Ingress Protection	IP66
Vandal Resistance	IK10
ELECTRICAL
Input Voltage / Current	24V AC ±10%
Power Consumption	Max. 24W (Heater Off), Max. 65W (Heater On)
MECHANICAL
Color / Material	Ivory / Plastic + Metal
Dimensions (WxH)	Ø220.0 x 293.6mm (Ø8.66" x 11.56")
Weight	3.3Kg (7.28 lb)

Datasheet

Product Attributes

Catalogue No

HCP-6230H

Brand

Samsung Techwin

Delivery

3 - 5 Days
