Genie CCTV WONVR14P5 Optimised Wish IP H.265 4 CH NVR 5MP PoE

Catalogue No: WONVR14P5

£127.50

~~£150.00~~

Saving Of

£22.50 (15%)

(Exc. 20% VAT)

(£153.00 Inc. VAT)

Delivery info

–

Genie Certified Surveillance Hard Drive 3.5" Sata - 1TB

+ £55.94

Genie Certified Surveillance Hard Drive 3.5" Sata - 2TB

+ £75.76

Genie Certified Surveillance Hard Drive 3.5" Sata - 4TB

+ £115.38

Genie Certified Surveillance Hard Drive 3.5" Sata - 6TB

+ £180.65

Genie Certified Surveillance Hard Drive 3.5" Sata - 8TB

+ £231.93

Genie Certified Surveillance Hard Drive 3.5" Sata - 10TB

+ £350.00

Information

Genie CCTV WONVR14P5 Optimised Wish IP H.265 4 CH NVR 5MP PoE

The Genie ‘Optimised’ WONVR14P5 PoE Network video recorder offers 4 channel recording of up to 5 Mega Pixels on every channel. The WONVR14P5 NVR supports 4 channel simultaneous playback and has 4 PoE ports.

Key Features

Supports 4 and 8 channel 5MP, 4MP, 3MP, 1080P, 960P and 720P IP input
Adopt standard H.265 and H.264 high profile compression format to get high quality video at much lower bit rate
Intuitive and user friendly Graphic User Interface (GUI), Windows style operation by mouse
Multi-mode recording: Manual / Timer / Motion / Sensor
4 and 8 channel simultaneous playback
Search : Time slice, time, event (Manual, sensor, motion), Tag search
Express and flexible backup via USB, network etc.
Pentaplex : Preview, record, playback, backup and remote access
DHCP, DDNS, PPPoE network protocol and CMS supported
Remote control via IE or CMS : Preview, playback, backup, PTZ and configuration
Immix platform is supported – running firmware 1.1.0 or later
Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
Multi user online simultaneously
Authorisation management, log view and device status view
1080P HD output, true high resolution display
Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
Support NAT function and QR code scanning by mobile phone and iPad
Powerful smart phone & iPad surveillance with iOS and Android OS

Specifications

Weight: 0.8 kg

OS: Embedded Linux

Network Access Format: 5MP / 4MP / 3MP / 1080p / 960p / 720p @ 25 / 30fps

Compression: Standard H.265, H.264

Network Input: 4 CH IPC audio input

Audio Local Output: No (HDMI supports the audio output)

Record Stream: Dual stream recording

Resolution: 5MP / 4MP / 3MP / 1080p / 960p / 720p @ 25 / 30fps

Mode: Manual, Timer, Motion, Sensor

Mobile OS: iOS, Android

Storage: HDD: SATA x 1, up to 6TB per HDD

Simultaneous Playback: 4 CH max.

Search: Time slice / Time / Event / Tag search

Smart Search: Highlighted colour to display the camera record in a certain period of time, different colours refer to different record events

Network Interface: RJ45 100 Mbps x 1

Protocol: TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP

IP Input Access / Transfer Bandwidth: 32Mbps / 32Mbps

Alarm Mode: Manual, Sensor, Motion, Exception

Input: No

Output: No

Triggering: Record, Snap, Preset, E-mail, etc.

Remote Monitoring

Immix: Compatible with Immix via RTSP only (2-way audio not supported)

Sentinel: Yes, Firmware 1.1.0 or later

Local Backup: USB stick, USB mobile HDD

Network Backup: Yes

USB Port: USB 2.0 x 2

Remote Controller: Optional

Power Supply: DC12V, 1.5A

Consumption: <6W (Without HDD)

Working Environment: Temperature: -10°C – 50°C,
Humidity: 10% – 90%

Dimensions: 255 x 234 x 42 mm

Datasheet

Product Attributes

Catalogue No

WONVR14P5

Brand

Genie CCTV
