UNIVIEW UNVR304-32s 32 Channel AI 16 4 SATA HDDs 12MP NVR

UNIVIEW UNVR304-32s 32 Channel AI 16 4 SATA HDDs 12MP NVR
UNIVIEW UNVR304-32s 32 Channel AI 16 4 SATA HDDs 12MP NVR
Catalogue No: UNVR304-32S-BB
£322.65
(Exc. 20% VAT)
(£387.18 Inc. VAT)
–
+
UNV Uniview
Information

UNIVIEW UNVR304-32s 32 Channel AI 16 4 SATA HDDs 12MP NVR

32CH NON PoE dual network NVR allows you to segregate your network to keep your camera traffic off the local network for installations where extra security is required. 160Mbps incoming bandwith to increase performance. Supports Ultra H.265 U-Code to reduce bandwidth and increase storage when using UNV cameras. Supports UNV AI false alarm filtering, cloud firmware upgrades plus many more features.

Key Features

  • 32CH NVR with Dual Network Interface
  • 4 x HDD Upto 40TB
  • AI Notifications on Humans / Vehicles
  • Connect Upto 8MP (4K) IP Cameras
  • Upto 4K HDMI / VGA monitor outputs
  • EZView Ap & Desktop Software
  • Ultra H.265 (U-Code) Compression
  • ONVIF Compatible
Specifications
Brand Uniview
Range Easy
Inputs for IP cameras LAN port up to 32 channels
Power over Ethernet No
IP compatible cameras UNIVIEW, ONVIF
Bidirectional audio 1 input / 1 RCA output
Video outputs 1 HDMI 4K, 1 VGA
Video compression format Ultra H.265 / H.265 / H.264
Display resolution 3840x2160, 1920x1080, 1600x1200 1280x1024, 1280x720, 1024x768
Total bandwidth 160 Mbps downstream / 64 Mbps upstream
Main Stream recording 8Mpx / 5Mpx / 4Mpx / 3Mpx / 1080p / 960p / 720p / 960H / D1 / 2CIF / CIF
Alarms No
Recording method Manual, programmed, motion detection
Intelligent functions People Counting, Face Detection, Intrusion Detection, Line Crossing, Scenery Change, Blur Detection, Auto Tracking, Removed object, Abandoned object
Smart Intrusion Prevention Available at 8 channels
External Backup USB / HDD USB memory
Internal memory 2 SATA HDD 3.5" of up to 6 TB (not included)
Communication 2 x USB 2.0 / 1 x USB 3.0 / 2 x RJ45 (Ethernet)
Remote access EZStation Web Browser, Smartphone App and PC Software
Power DC 12 V / 15 W, 50/60 Hz
Dimensions / Weight 50 (H) x 440 (W) x 344 (D) mm / 3.15 Kg
Datasheet
Product Attributes
Catalogue No
UNVR304-32S-BB
Brand
UNV Uniview
Warranty
3 Years or 1 without HDD
HD Format
H.265 H.264
Resolution
12MP
SATA HDD
4 SATA 32TB max
Max Cameras
32 (IP)
