CDVI CDV47DX-W 2Easy 2 wire 7" slim touch screen wifi memory monitor
The CDV47DX is a 2-wire, 7-inch digital colour, TFT monitor with touch screen and picture/video memory.
The CDV47DX is the latest upgrade for the CDV47 now including Wi-Fi connection and a new mobile app allowing users to control access from their phone by receiving calls or remotely releasing multiple locks.
The 2EASY system from CDVI offers convenient and high quality video entry. Connection throughout is 2-wire, non polarised, so installation and maintenance is simple and straightforward.
Single call button, system design tips:
Single call button systems only support 1 X CDV47DX wi-fi monitor - for additional monitors please select from list of compatible part numbers below
- CDV-47-B (matching 7" touchscreen hands free monitor non wi-fi curretly only available in black)
- CDV-43 (4.3" hands free monitor, neat design with touch buttons built in only available in white)
- CDV-24 (4" wall mounted monitor with handset on coiled wire ideal for noisy environments only available in white)
- CDV-17HFA (Audio only hands free unit ideal for lesser used areas i.e. attic landing, garden shed etc.
Don't forget, if you order additional monitors you should order a 4 way distributor for systems up to 4 monitors in total - part No. CDV-DBC4A
For wiring diagrams, see below
For larger systems with multiple call buttons, please call us for design support
- Built-in picture/video memory
- Name list editing by built in keypad
- Intercom function
- Mobile app available on Android and IOS - Free of charge operation (no monthly or yearly subscription fees)
- Call recording management
- Compatible with all CDVI door stations
- Easy upgrade for existing users. Simply change the monitor within the system.
Wiring is simple
2 wires, non-polarised
Monitor screen: 7 inch digital colour TFT
Video signal: 1Vp-p, 75Ω, CCIR standard
Display resolutions: 800*3 (R, G, B) x 480 pixels
Power input: 12/24 Vdc
Power supply: 20 to 28 Vdc for indoor monitor
Power consumption: 7W (working), 0.3W (standby)
Dimensions: 132 x 226 x 18mm
2 Doors to 4 monitors using 2 core cables
Diagram shows 2 X CDV91-SF connected to CDV-DBC4A connected to CDV-PC6 output to CDV-DBC4A with 4 X CDV47 monitors
Other combinations can be used to achieve any configuration required up to 4 entrances maximum, you can combine different monitors and even use audio only for lesser used locations, i.e. in the cellar.
